Speedhut 2-5/8″ 0-14.0 Bar Oil Pressure Gauge w/ Warning (R25-OP5-REV)

Description

The Speedhut 2-5/8″ 0-7.0 Bar Oil Pressure Gauge w/ Warning (R25-OP4-REV) provides precise monitoring of your vehicle’s engine oil pressure. This metric gauge, with a range of 0 to 7 bar, is designed to give you accurate and reliable readings, ensuring you are always aware of your engine’s critical lubrication status. The integrated warning light adds an extra layer of security, alerting you to potential issues before they become major problems. This gauge is built with quality components, including a high-performance 3-wire military-grade transducer, ensuring accurate and consistent measurements.

KEY FEATURES AND BENEFITS:

• Accurate Oil Pressure Monitoring: Precisely displays oil pressure within a 0-7 bar metric range, allowing for careful monitoring of engine health.
• Integrated Warning Light: Features a built-in warning light that can be configured to illuminate when oil pressure falls below a critical level, providing immediate visual alerts.
• High-Performance Sender: Includes a 3-wire military-grade pressure transducer, known for its reliability and accuracy in demanding conditions.
• Metric Measurement: Provides readings in the widely used metric unit of bar, ensuring compatibility with a broad range of vehicles and systems.
• Convenient Size: The 2 5/8 inch gauge size (68mm hole) is a popular and versatile dimension, fitting into many standard gauge pods and mounting locations.
• Complete Wiring Included: Ships with all necessary wiring harnesses, simplifying the installation process.

SPECIFICATIONS:

• Standard or Metric: Metric
• Gauge Type: Pressure Gauge
• Gauge Subtype: Oil Pressure Gauge
• Pressure Sender Type: 3-Wire Military Grade Transducer (Performance)
• Range: 0-7 bar
• Size: 2 5/8 inch
• Hole Size: 2.67 inches (68mm)
• Warning Light: Yes
• Ships With:
• Pressure Sensor – 100 psi
• 3 ft Power & Lighting Harness – for LED Lit Gauges and Clocks
• Pressure Gauge Wiring Harness (3-Wire Cable)

HOW TO USE:

1. Preparation: Identify a suitable mounting location for the 2 5/8 inch gauge, ensuring enough clearance behind the dashboard for the gauge and wiring.
2. Gauge Installation: Carefully insert the gauge into the 2.67-inch (68mm) hole, securing it using the appropriate mounting hardware (not typically included, as it varies by installation).
3. Sender Unit Connection: Locate the oil pressure port on your engine. Install the included pressure sensor (100 psi) into this port. Connect the 3-wire cable from the gauge to the corresponding terminals on the pressure sensor.
4. Power and Lighting Connection: Connect the 3 ft power and lighting harness to the gauge. Typically, this involves connecting to a 12V power source (ignition switched is recommended), ground, and the vehicle’s lighting circuit if you desire the gauge to illuminate with your headlights.
5. Warning Light Setup: The warning light functionality will likely require a specific wiring connection as detailed in the Speedhut documentation (refer to the manufacturer’s instructions for precise wiring and threshold configuration for the warning light).
6. Testing: Once all connections are made, start your vehicle and observe the gauge readings to ensure proper function. Check that the warning light activates as expected under low-pressure conditions (if configuration is possible).

BENEFITS OF USING THE SPEEDHUT 2-5/8″ 0-7.0 BAR OIL PRESSURE GAUGE W/ WARNING (R25-OP4-REV):

• Proactive Monitoring: Allows you to detect and address oil pressure issues early, helping prevent costly engine damage.
• Enhanced Safety: Integrated warning light offers immediate alerts, enabling quick corrective action.
• Reliable Readings: Military-grade transducer ensures high accuracy and consistent performance.
• Metric Compatibility: Displays pressure in bar, a widely used measurement unit internationally.
• Ease of Installation: Includes all necessary wiring for a streamlined setup.

FEATURES:

• Provides real-time oil pressure readings in metric units (bar).
• Equipped with a bright, noticeable warning light for immediate alerts.
• Utilizes a robust 3-wire military-grade transducer for consistent accuracy.
• Designed with a common 2 5/8 inch diameter for flexible mounting choices.
• Includes essential wiring harnesses for straightforward installation.
• Offers a 0-7 bar measurement range suitable for a variety of applications.
• Features a durable construction built to withstand automotive environments.
• Contributes to preventative maintenance by highlighting potential lubrication issues.
