Description
The RTi-MGD is the optimum choice in compact energy saving condensate drains. Unlike timed or electronic drains which require electricity to operate, the RTi-MGD operates using a magnetic level sensor providing energy saving zero air loss operation without the need for a power source. It’s perfectly suited for coolers, refrigerated dryers, liquid separators, and especially compressed air filters (due to its compact size). The RTi-MGD meets the demands of most applications regardless of the condensate flow. It fits any compressed air filter regardless of size without any set up or adjustment.
Features
•Extremely compact, easy to install in tight locations
•No electricity required
•No operating costs, perfect for all applications, especially those where electricity is not available
•Reliable operation with most condensate
• Rugged aluminum housing; lightweight, yet strong and durable
| Technical Specifications | |
| Max. drainage capacity/output | 54 gallons per hour |
| Inlet connection height | ½” |
| Outlet connection | ⅛” |
| Min. system pressure | 0 PSI |
| Max. system pressure | 230 PSI |
| Min. medium temperature | 34°F |
| Max. medium temperature | 122°F |
| Type of operating valve | 2/2 way, direct acting valve assy |
| Valve seals | Viton (FPM) |
| Housing material | Corrosion resistant Aluminum |
| Height | 5.39″ |
| Width | 4.72″ |
