Description
PCE Instruments Microohm Meter (PCE-MO 3001) is a professional measuring device designed for accurate low-resistance testing. With a resolution of 0.1 μΩ and six selectable measurement ranges, this device is ideal for precise electrical resistance measurements. It utilizes a 4-wire test method, ensuring reliable and accurate results by minimizing errors caused by lead resistance.
The internal rechargeable battery ensures extended operation, while its high test current capability of up to 1 A makes it suitable for detecting even the smallest resistances. This microohm meter is widely used in industries where precise resistance measurements are required, including electrical maintenance, circuit testing, and component evaluation.
- Specifications and Dimensions
- Measurement Ranges and Accuracy:
- 2,000 mΩ / 1 µΩ / ± (5 % + 5 digits)
- 20,00 mΩ / 10 µΩ / ± (4 % + 4 digits)
- 200,0 mΩ / 100 µΩ / ± (4 % + 4 digits)
- 2000 mΩ / 1 mΩ / ± (3 % + 4 digits)
- 20,00 Ω / 10 mΩ / ± (2 % + 4 digits)
- 200,0 Ω / 100 mΩ / ± (2 % + 4 digits)
- Test Current:
- 10 mA (200 Ω range)
- 100 mA (20 Ω, 2 Ω ranges)
- 1 A (200 mΩ, 20 mΩ, 2 mΩ ranges)
- Test Current Accuracy:
- 10 mA ±1.5 %
- 100 mA ±2.0 %
- 1 A ±3.0 %
- Maximum Output Voltage: 0 V RMS
- Power Supply: Internal rechargeable battery
- Casing: Polycarbonate, ABS
- Dimensions: 330 x 260 x 160 mm
- Weight: 3.8 kg
- Safety Standard: EN 61010-1
- Measurement Ranges and Accuracy:
- Key Features and Benefits
- High-precision microohm meter with a resolution of 0.1 μΩ
- 6 measurement ranges with selectable test currents
- Uses 4-wire test method to minimize lead resistance errors
- Large LCD for clear and easy readings
