Jet JTM-949EVS Mill Acu-Rite 200S DRO XY-Axis Pwrfd & APDB (690523)

Description

Jet JTM-949EVS Mill Acu-Rite 200S DRO XY-Axis Pwrfd & APDB (690523) is a versatile and well-equipped milling machine for various metalworking applications. Its Meehanite cast iron base and column ensure rigidity and vibration dampening for accurate results. The variable speed spindle (60-4,500 RPM) allows for precise control over cutting speeds for different materials. X and Y-axis power feeds automate table movements, improving efficiency and reducing operator fatigue. The JTM-949EVS also features a pneumatic drawbar for effortless tool changes and an Acu-Rite 200S digital readout (DRO) for accurate positioning.

KEY FEATURES AND BENEFITS:

• Rigid Meehanite cast iron construction: Ensures long-lasting performance and minimal deflection.
• Variable speed spindle (60-4,500 RPM): Allows optimal cutting speeds in various materials.
• X and Y-axis power feeds: Automate table movement and increase productivity.
• Pneumatic drawbar: Enables fast and easy tool changes.
• Acu-Rite 200S digital readout (DRO): Provides precise positioning and measurement.
• Automatic oiler: Extends machine life by lubricating components regularly.
• Heavy-duty spindle brake: Enhances safety by stopping the spindle quickly.
• Durable components: Includes class 7 spindle bearings and hardened ways for long-lasting operation.
• User-friendly features: Swing-away control box with conveniently placed E-stop button.
• Versatility: Handles a wide range of milling tasks with variable speed control, power feeds, and multiple table movements.

SPECIFICATIONS:

• Digital Readout: Acu-Rite 200S
• Number of Axis: 3 (Knee)
• Powerfeed: X and Y-Axis
• Power Drawbar: Pneumatic
• Table Size (L x W) (in.): 9 x 49
• Quill Diameter (in.): 3-3/8
• Spindle Speeds: Variable
• Spindle Speed Range (RPM): 60 – 4,500
• Quill Down Feed Rates (IPR): .0015 – .003 – .006
• Spindle Travel (in.): 5
• Head Movement (deg.): 90° R & L, 45° F & B
• Max Distance Spindle to Table (in.): 20-3/4
• Motor (HP): 3HP, 230V, 3Ph
• Overall Dimensions (L x W x H) (in.): 67 x 64 x 86
• Weight (lbs.): 2,420

HOW TO USE:

1. Installation: Secure the machine to a stable and level surface. Refer to the user manual for specific installation instructions.
2. Set up the workpiece: Clamp the workpiece securely to the mill table using a vise or appropriate hold-down clamps.
3. Adjust the spindle speed and feed rate: Choose the appropriate settings based on the material and desired cutting depth.
4. Position the cutting tool: Install the desired cutting tool into the spindle and use the quill feed to adjust its depth.
5. Engage the power feed (optional): If using the power feeds, activate them for automated table movement during cutting.
6. Operate the machine: Start the spindle and begin cutting the workpiece according to your desired profile.
7. Monitor the process: Pay close attention to the cutting operation and adjust parameters as needed.
8. Machine shutoff: Once finished, power off the machine and allow the spindle to stop completely before disengaging any clamps or handling the workpiece.

BENEFITS OF USING Jet JTM-949EVS Mill Acu-Rite 200S DRO XY-Axis Pwrfd & APDB (690523):

• Accurate and precise metalworking: Rigid construction, variable speed control, and DRO ensure precise cuts.
• Increased productivity: Power feeds automate table movements, saving time and effort.
• Efficiency and ease of use: User-friendly features like a swing-away control box and automatic oiler enhance operation.
• Versatility: Handles a wide range of milling tasks with various materials.
• Durability: Built with high-quality components for long-lasting performance.

FEATURES:

• Meehanite cast iron base and column
• Variable speed spindle (60-4,500 RPM)
• X and Y-axis power feeds
• Pneumatic drawbar
• Acu-Rite 200S digital readout (DRO)
• Automatic oiler
