Jet JTM-1254RVS Mill w/ACURITE200S 3X (Q) DRO & XYZ Powerfeed (698124)

Description

Jet JTM-1254RVS Mill w/ACURITE 200S 3X (Q) DRO & XYZ Powerfeed (698124) is a high-performance vertical milling machine designed for professional machinists. It delivers exceptional precision and durability for a wide range of applications.

KEY FEATURES AND BENEFITS

• Precision Machining:
  • Certified Meehanite® castings, precision-bored head, high-grade bearings ensure accuracy and reduce vibration.
• Heavy-Duty Construction:
  • Built for demanding tasks with a rigid cast iron base and powerful 5 HP motor.
• Variable Speed Control (80-3,800 RPM):
  • Offers versatility for handling various materials and applications.
• Automatic Lubrication:
  • Minimizes maintenance and extends machine life.
• User-Friendly Design:
  • Quick nut spindle feed, adjustable gibs, and digital readout (DRO) for ease of use.
• Power Feeds (X, Y, Z):
  • Automate repetitive tasks and improve machining efficiency.
• Large Table (12″ x 54″):
  • Provides ample workspace for handling bigger workpieces.
• R-8 Spindle Taper:
  • Compatible with a wide range of tooling options.
• Easy Leveling:
  • Innovative cast iron design simplifies machine leveling without lifting.

SPECIFICATIONS

• Table Size (L x W): 12 x 54 in.
• Spindle Taper: R-8
• Spindle Speeds: 80-3,800 RPM
• Quill Travel: 5 in.
• Power Feed Axes: X, Y, Z
• Motor: 5 HP, 3-Phase (230V or 460V)
• Overall Dimensions: 92-1/8 x 79-7/8 x 104-1/4 in.
• Weight: 3,969 lbs.

HOW TO USE

1. Installation: Refer to the user manual for proper installation instructions, including electrical connections and initial setup.
2. Workpiece Setup: Secure your workpiece to the milling table using clamps or a vise, ensuring proper alignment and safety.
3. Tooling Selection: Select appropriate cutting tools (end mills, drills, etc.) based on your material and desired machining operation.
4. Speed and Feed Selection: Set the spindle speed and feed rate according to the material, tool size, and desired cut depth using the variable speed control and feed dials.
5. Machining: Operate the machine controls to perform milling operations, utilizing the power feeds for automated movements along X, Y, and Z axes.
6. Safety: Always wear proper safety gear (eye protection, gloves, etc.) and follow safe machining practices outlined in the manual.

BENEFITS OF USING Jet JTM-1254RVS Mill w/ACURITE 200S 3X (Q) DRO & XYZ Powerfeed (698124)

• High-Quality Machining: Achieve precise results for demanding projects with exceptional rigidity and component quality.
• Increased Efficiency: Power feeds automate repetitive tasks, saving time and effort.
• User-Friendly Operation: Automatic lubrication, quick adjustments, and a digital readout simplify operation.
• Versatility: Variable speed control and a wide range of compatible tooling handle diverse machining needs.
• Durability: Built for long-lasting performance with robust construction and high-quality materials.

FEATURES

• Certified Meehanite® castings for superior rigidity and vibration damping.
• Precision bored and honed milling head for accurate machining.
• High precision Class 7 spindle bearings for smooth operation.
• Quick spindle feed nut for fast and easy tool changes.
• Three-stage power downfeed with automatic stop for consistent depth control.
• Heavy-duty spindle brake for quick stopping power.
• Precision hardened and ground ways and table for smooth travel.
• Three precision ground T-slots for versatility.
• Turcite B on X & Y Axis for wear resistance.
• Adjustable gibs throughout for precise fit and alignment.
• CSA/CUS certified to meet strict electrical safety standards.
• ACU-RITE 200S digital readout (DRO) for easy and accurate positioning.
• Spindle guard for operator safety.
• LED machine lamp for improved visibility.
• Dual locks on all moveable surfaces for stability.
• Chip pan for easy chip collection.
• Drawbar for quick and easy tool removal.
• Toolbox with tools for common maintenance tasks.
