Irwin 1/4″ – 28 NF HCS Hexagon Machine Screw Die (9423)

Description

The Irwin 1/4″ – 28 NF HCS Hexagon Machine Screw Die (9423) is a specialized threading tool crafted for precision and adaptability. This die is engineered to create and repair external machine screw threads with a 1/4-inch diameter and a fine pitch of 28 threads per inch. Made from high carbon steel, it provides the necessary hardness and durability for manual threading on various materials.

KEY FEATURES AND BENEFITS:

• Precision Threading: Cuts clean and accurate 1/4″ – 28 NF (National Fine) threads for secure and proper machine screw fits.
• Versatile Hexagon Shape: Can be driven by a die stock, wrench, or socket, allowing threading in tight or confined spaces.
• High Carbon Steel Construction: Provides hardness and toughness for a reliable, long-lasting cutting edge in hand threading.
• Ideal for Repair and Maintenance: Recommended for restoring damaged threads or creating new ones on various components.

SPECIFICATIONS:

• Thread Size: 1/4″ – 28 NF
• Material: High Carbon Steel (HCS)
• Shape: Hexagon
• Outside Diameter: 1″
• Thickness: 3/8″
• Thread Direction: Right-hand

HOW TO USE:

• Prepare the Workpiece: Securely clamp the rod or bolt in a vice; bevel the end to start the die squarely.
• Mount the Die: Insert the hexagon die into a die stock, wrench, or socket and secure firmly.
• Start the Thread: Place the die squarely on the workpiece end, apply downward pressure, and turn clockwise to begin threading.
• Cut the Thread: Continue turning clockwise with steady pressure; reverse the die a quarter turn after every full turn or two to break chips.
• Finish the Thread: Repeat forward and backward turning until the desired thread length is reached. Remove the die by turning counter-clockwise and clean threads with a brush.

BENEFITS OF USING IRWIN 1/4″ – 28 NF HCS HEXAGON MACHINE SCREW DIE (9423):

• Adaptability through its hexagonal shape allowing multiple driving options.
• Efficient thread cutting and restoration, reducing downtime.
• Durable high carbon steel construction ensures long tool life.
• Produces precise National Fine standard threads for proper fastener fit.

FEATURES:

• Hexagonal body for use with wrench or socket in confined areas.
• Designed for creating right-hand threads.
• Constructed from high carbon steel for durability and sharp cutting ability.
• Engineered to cut 1/4-inch diameter fine threads with 28 threads per inch.
• Suitable for both professional and home workshop use.
