Description
Grizzly Industrial 12″ x 35″ Variable-Speed Gunsmith Lathe (G0949G) offers precision and power for gunsmithing and metalworking projects. With a robust 1-1/2 HP motor and variable-speed control across two ranges, this lathe is ideal for producing accurate threads, smooth finishes, and complex components.
Designed for versatility and durability, this gunsmith lathe includes a D1-4 camlock spindle, quick-change tool post, and steady and follow rests with brass supports for enhanced precision. The built-in spindle speed digital readout ensures consistent performance, while the full-length splash guard.
- Specifications and Dimensions
- Main motor: 1-1/2 HP, 110V, single-phase, 15A
- Swing over bed: 12-5/8″
- Swing over saddle: 10-1/2″
- Swing over cross slide: 7-3/4″
- Distance between centers: 34-5/8″
- Spindle nose: D1-4 camlock
- Tailstock quill travel: 3-1/8″
- Cross slide travel: 6-1/2″
- Compound travel: 3-3/8″
- Spindle speeds: Variable, 100–515 RPM and 390–2000 RPM
- Range of threads (inches): 21 @ 8-56 TPI
- Range of threads (metric): 12 @ 0.4-3.5 mm
- Overall dimensions: 65″ W x 30-1/2″ D x 53″ H
- Approximate shipping weight: 850 lbs.
- Key Features and Benefits
- Digital spindle speed readout for precise control
- Variable-speed control through two-speed ranges
- Outboard spindle support spider with 4 brass-tipped bolts
- Steady and follow rests with brass supports for smooth operation
- 200-Series quick-change tool post with two holders included
- Stand with three storage drawers and one cabinet for organized tools
- D1-4 camlock spindle for quick and secure workholding
