Description
The FiTech Ultra Ram EFI 800 HP Chevy Big Block Master Kit (93632) offers a comprehensive solution for converting LS engines to electronic fuel injection. Designed for up to 800 horsepower, this kit includes everything needed for a complete EFI upgrade, featuring a sheet metal Ultra Ram intake manifold, a 102mm throttle body, and a robust fuel delivery system. The self-tuning ECU simplifies installation and optimizes engine performance, making it suitable for both DIY enthusiasts and professional tuners.
KEY FEATURES AND BENEFITS:
- Supports up to 800 horsepower for high-performance applications.
- Includes a complete in-tank fuel system with a 340 or 440 lph pump module.
- Features a 102mm throttle body for increased airflow.
- Self-tuning ECU simplifies setup and optimizes fuel/air mixture.
- Go-Spark CD ignition for improved starting and throttle response.
- Adjustable fuel pressure regulator (30-70 psi) supports high-horsepower needs.
SPECIFICATIONS:
- Maximum Horsepower: 800 hp
- Fuel Injection Style: Multi-port
- Throttle Body Size: 102mm
- Injector Size: 55 lbs/hr
- Fuel Pump: In-tank, 340 or 440 lph
- Fuel Pressure Regulator: 30-70 psi adjustable
- Ignition: Go-Spark CD ignition
- Throttle Body Mounting Flange: GM LS2 4 bolt
- Intake Material: Aluminum
- Metering Style: Speed density
HOW TO USE:
- Preparation: Disconnect the battery and remove the existing carbureted intake and fuel system.
- Fuel System Installation: Install the in-tank fuel pump module within the fuel tank, ensuring proper line routing and connections.
- Intake and Throttle Body Installation: Mount the Ultra Ram intake manifold and 102mm throttle body onto the engine.
- Sensor and Wiring Installation: Install all included sensors (MAP, IAT, TPS, etc.) and connect the wiring harness to the ECU and engine components.
- Ignition System Installation: Install the Go-Spark CD ignition system, connecting it to the distributor and power source.
- ECU Setup: Mount the ECU and connect the handheld controller. Input basic engine specifications into the controller.
- Initial Start-Up: Reconnect the battery and start the engine. The self-tuning ECU will begin to optimize fuel/air mixture.
- Fuel Pressure Regulation: Set the fuel pressure to the desired PSI.
- Fine-Tuning: Monitor engine performance and make any necessary adjustments using the handheld controller.
BENEFITS OF USING THE FITECH ULTRA RAM EFI 800 HP CHEVY BIG BLOCK MASTER KIT (93632):
- Improved engine performance and horsepower output.
- Enhanced throttle response and drivability.
- Simplified installation with self-tuning capabilities.
- Complete kit eliminates the need for individual component sourcing.
- Reliable fuel delivery and ignition for consistent engine operation.
- Increased fuel efficiency.
FEATURES:
- Sheet metal Ultra Ram intake manifold design.
- In-tank fuel pump module with -6 AN ORB ports.
- Go Fuel Tight Fit regulator with pressure gauge.
- Remote mount ECU with comprehensive wiring harness.
- Handheld color touch screen controller.
- Wideband oxygen sensor and bung kit included.
- 1450 cfm airflow rate.
