Description
Magnetically-operated sensing devices for sending system data to the controller or PLC.
-
Available in 115 VAC or 12-32 VDC
-
Available for all series progressive families to provide cycle rates up to 200 CPM
-
Pressure ratings up to 10,000 psi (690 bar)
-
Variety of electrical connections and voltages with or without LED indication
-
Select models available with UL and CSA approvals
UPC Product: 00633955343085 Family Code: FAMCPT Unit of Measure: EA Height: 2.5 IN |6.35 CM Length: 6.1 IN |15.494 CM Width: 4.5 IN |11.43 CM Volume: .04 FT3 |.001 M3 Chargeable Weight: .79 LBS | .36 KG
Technical Specifications
| Material | 303 Stainless Steel, Buna-N |
|---|---|
| Type | Field-Sensing Magnetic |
| Maximum Working Pressure (bar) | 689 |
| Maximum Working Pressure (kPa) | 68900 |
| Power Connection Type | 4-Pin CH Mini |
| Maximum Working Pressure (psi) | 10000 |
| Compatible Material | Oil, Grease |
| Amperage (A) | 1 |
| Maximum Working Pressure (MPa) | 69 |
