Description
Used for sealant and adhesive materials
UPC Product: 00633955697065 Family Code: FAMAPA Unit of Measure: EA Height: 9.6 IN |24.384 CM Length: 8.1 IN |20.574 CM Width: 5 IN |12.7 CM Volume: .225 FT3 |.006 M3 Chargeable Weight: 3.89 LBS | 1.76 KG
Technical Specifications
| Air Inlet Size (cm) | 0.3175 |
|---|---|
| Air Inlet Size (in) | 1/8 |
| Air Inlet Size (mm) | 3.175 |
| Air Inlet Thread Gender | Female |
| Air Inlet Thread Type | NPT |
| Compatible Material | Sealants, Adhesives |
| Fluid Inlet Size (cm) | 1.27 |
| Fluid Inlet Size (in) | 1/2 |
| Fluid Inlet Size (mm) | 12.7 |
| Fluid Inlet Thread Gender | Female |
| Fluid Inlet Thread Type | NPT |
| Fluid Outlet Size (cm) | 1.5875 |
| Fluid Outlet Size (in) | 5/8-18 |
| Fluid Outlet Size (mm) | 15.875 |
| Fluid Outlet Thread Gender | Male |
| Fluid Outlet Thread Type | UNF |
| Maximum Working Pressure (bar) | 345 |
| Maximum Working Pressure (kPa) | 34500 |
| Maximum Working Pressure (psi) | 5000 |
| Type | Dispense Valve |
| Component Type | Single Component |
| Ambient/Warm Melt/Hot Melt | Ambient;Warm Melt |
| Gun Activation | Automatic |
| Application | Bonding, Sealing, Gasketing |
| Maximum Working Pressure (MPa) | 34.5 |
| Orifice Diameter (in) | 0.125 |
| Outlet Size (in) | 5/8-18 |
| Outlet Size (cm) | 1.5875 |
| Model | Endure |
