Description
Keep your machine running while lubrication gets to critical points. These performance indicators pinpoint lube line blockages but allow the lube system to continue to supply lubrication to points that are not blocked.
- No time or effort required for reset after blockage is cleared
- Easy information on blocked lines, high system pressure or blocked bearings
- Works with MSP, MX, MXP, MJ and MHH divider valves
UPC Product: 00633955331273 Family Code: FAMCPT Unit of Measure: EA Height: .45 IN |1.143 CM Length: 1.35 IN |3.429 CM Width: .5 IN |1.27 CM Volume: 0 FT3 |0 M3 Chargeable Weight: .07 LBS | .03 KG
Technical Specifications
| Application | On-Road Vehicles, Off-Road Equipment, Compressor Equipment |
|---|---|
| Compatible Material | Oil, Grease |
| Connection Size (in) | 0.125 |
| Includes | O-Ring |
| Indicator Type | Automatic Relief Indicators |
| Maximum Working Pressure (bar) | 172 |
| Maximum Working Pressure (kPa) | 17200 |
| Maximum Working Pressure (psi) | 2500 |
| Overall Length (cm) | 3 |
| Overall Length (in) | 1.37 |
| Overall Length (mm) | 35 |
| Thread Type | NPT |
| Type | Relief Valve |
| Maximum Working Pressure (MPa) | 17 |
| Model | Trabon |
